Grundfos Unilift AP35-40-06-AV1 0.60kW Submersible Vortex Drainage Pump (Max 300LPM/90kPa)
The Grundfos Unilift AP35-40-06-AV1 Vertical single-stage stainless steel submersible pump with vertical discharge port and integrated submersible 3-phase totally enclosed motor in insulation class F. The pump is fitted with a suction strainer. The pump is supplied with a control box including motor starter, a motor protection and a float switch for automatic start/stop of the pump . The float switch contains 10 m cable. And there is a 0.8m maine cable connected to the box (see electrical data for optional CEE plug).
The impeller is a VORTEX impeller for groundwater, surface water, rain water and similar liquids. The pump has a double shaft seal and an intermediate oil chamber pre-filled with non-toxic special oil. The pump has a riser pipe, a cooling jacket for continuous cooling of the motor by the pumped liquid and long-life deep-groove greased-for-life ball bearings.
The pump is ready for use as it is fitted with carrying handle and is supplied with a 10 m mains cable. The mains cable is of the plug type with glass sealing compound in the socket to prevent penetration of humidity into the stator windings.
SPECIFICATIONS
- Maximum flow: 4.17l/s
- Maximum head: 10m
- Max particle: 35mm
- Rated speed: 2795 rpm
- Pump housing: Stainless Steel
- Impeller: Stainless Steel
- Cable union: Brass
- Range of ambient temperature: 0..55°C
- Size of connection: 1 1/2 inch
- Maximum installation depth: 7m
- Liquid temperature range: 0..55°C
- Rated voltage: 1 x 230v
- Rated current: 3.1A
- Length of power cable: 10m
- Float switch included: Yes
